Komodo III Quad CoaXPress 12G Frame Grabber

Features

Key Features:

• Quad CoaXPress links support
• Up to 4 Multi-streams
• PCI Express card
• PCIe 3.0 x8 bus
• 4 GB DDR4 frame buffer
• Camera controls and triggers
• Link Status LED indication
• Flexible GPIO interface:
– 4 TTL configurable I/Os
– 4 LVTTL configurable I/Os
– 2 LVDS inputs
– 2 LVDS outputs
– 4 opto-isolated inputs
– 4 opto-isolated outputs
– 4 quadrature rotary encoders
– Integrated strobe controller
– 4 timers
• CoaXPress v2.1 compliant
• Power over CoaXPress with 13 W per link
• Multiple camera synchronization
• Multiple Frame Grabbers synchronization
• Micro-BNC connectors for CoaXPress links
• GUI Interface
• Supporting Windows, Linux OS and Nvidia Jetpack
• API for custom application development
• Plug-in modules for Matlab, HALCON, Cognex and
Labview
• Gen<i>Cam compliant
• GenTL support
• Data rates up to 12.5 Gbps per link
• Transfer rates of up to 6,695 MB/s
• 0°C to +50°C operating environment temperatures

Ordering Code:

KY-FGK-III-CXP

Komodo III Quad CoaXPress is the best-in-class Frame Grabber, supporting the CoaXPress v2.1 standard. It can receive video streams from Quad CoaXPress v2.1 links in single, dual or quad modes. It can also be used for simultaneous capture from multiple cameras. Each link supports standard CoaXPress v2.1 bitrates of up to 12.5 Gbps. These features make the Komodo III Quad CoaXPress ideally suited for industrial, defense and aerospace Machine Vision Systems and applications

The Komodo III Quad CoaXPress can easily receive video streams on the CoaXPress links and transmit them to computer memory through the PCIe interface. This product also provides an external GPIO for machine control signals, such as triggers, timers, shaft encoders, exposure control and general I/O which can be controlled aside video stream acquisition. Our frame grabber uses standard Micro-BNC connectors as a CoaXPress v2.1 interface to the camera. It utilizes PCIe 3.0 x8 links for communication with Host PC for video uploading and configuration.

Specifications

Mechanical
Form factor	PCI Express card
Format	Standard profile, half length, 8-lane PCI Express card
Cooling method	Passive, requires airflow
Mounting	For insertion in a standard height, 8-lane or higher, PCI Express card slot
Connectors	• Ports 1 through 4 via x4 Micro-BNC connectors for CoaXPress v2.1 interface • x1 I/O connector HD DB26 D-sub panel mount (26-pin 3-row) on front bracket • Auxiliary 6-pin PEG power socket 12 VDC power input (for PoCXP) on PCB
Dimensions	167.65 mm x 111.15 mm (6.6″ x 4.4″)
Weight	296 g (10.4 oz)
Host Bus
Standard	PCI Express 3.0
Link width	• 8 lanes • 1, 2 or 4 lanes with reduced performance
Link speed	• 8.0 GT/s (PCIe 3.0) • 5.0 GT/s (PCIe 2.0) with reduced performance
Maximum payload size	2,048 bytes
DMA	• 64-bit addressing support • Scatter gather support • Physical address support (GPU transfers)
Peak delivery bandwidth	7,877 MB/s
Effective (sustained) delivery bandwidth	6,695 MB/s (Host PC dependent)
Power consumption	17 W, excluding camera and I/O power output
Camera / Video Inputs
Interface standard(s)	CoaXPress v2.1 (CoaXPress 1.0, 1.1, 1.1.1 and 2.0 backward compatible)
Status LEDs	• 1 bicolor status LED per camera connector • 4 System status LEDs
Number of cameras	Up to 4
Number of links per single camera	Up to 4
Number of streams per single camera	Up to 4
Total number of streams per frame grabber	Up to 4
Synchronization between cameras	Yes
Line-scan cameras supported	Yes
Maximum aggregated camera data transfer rate	50.0 Gbit/s
Supported down-connection speeds	• 1.25 Gbit/s (CXP-1) • 2.5 Gbit/s (CXP-2) • 3.125 Gbit/s (CXP-3) • 5 Gbit/s (CXP-5) • 6.25 Gbit/s (CXP-6) • 10 Gbit/s (CXP-10) • 12.5 Gbit/s (CXP-12)
Supported up-connection speeds	• Low-speed 20.83 Mbps (CXP-1 to CXP-6) • Low-speed 41.66 Mbps (CXP-10, CXP-12)
Maximum stream packet size	8,192 bytes
Power over protocol	• PoCXP Safe Power • 13 W of 24 V DC regulated power per CoaXPress connector • PoCXP Device detection and automatic power-on • Overload and short-circuit protections • On-board 12 V to 24 V DC/DC converter • A +12 V power source must be connected to the auxiliary power input connector
Camera types	Area-scan cameras: • Gray-scale and color (RGB and Bayer CFA) • Single-tap (1X-1Y) progressive-scan • Single-tap (1X-1Y) interlacedLine-scan cameras: • Gray-scale and color RGB
Camera pixel formats supported	Raw, Monochrome, Bayer, RGB, YUV, YCbCr and RGBA (PFNC names): • Raw • Mono8, Mono10, Mono12, Mono14, Mono16 • BayerXX8, BayerXX10, BayerXX12, BayerXX14, BayerXX16 where XX = GR, RG, GB, or BG • RGB8, RGB10, RGB12, RGB14, RGB16 • RGBA8, RGBA10, RGBA12, RGBA14, RGBA16 • YUV411 8, YUV411 10, YUV411 12, YUV411 14, YUV411 16 • YUV422 8, YUV422 10, YUV422 12, YUV422 14, YUV422 16 • YUV444 8, YUV444 10, YUV444 12, YUV444 14, YUV444 16 • YCbCr601 411 8, YCbCr601 411 10, YCbCr601 411 12, YCbCr601 411 14, YCbCr601 411 16 • YCbCr601 422 8, YCbCr601 422 10, YCbCr601 422 12, YCbCr601 422 14,YCbCr601 422 16 • YCbCr601 444 8, YCbCr601 444 10, YCbCr601 444 12, YCbCr601 444 14, YCbCr601 444 16
General Purpose Inputs and Outputs
Number of lines	20 I/O lines: • 2 differential inputs • 2 differential outputs • 4 singled-ended TTL inputs/outputs • 4 singled-ended LVTTL inputs/outputs • 4 opto-isolated inputs • 4 opto-isolated outputs
Usage	• Any System I/O input lines can be connected to any I/O output line • Any I/O input line can be used to decode A/B and Z signals of a motion encoder • Any I/O input line can generate any trigger event • Any I/O input line can trigger a timer
Electrical specifications	• Differential lines – LVDS compatible • TTL lines: 5 V TTL compliant • LVTTL lines: 3.3 V LVTTL compliant • Isolated lines: opto-isolated lines with voltage range up to 30 V
Filter control	• Glitch removal filter for Encoders and Triggers • Configurable filter time between 0 µs and 34 ms • Filter time resolution of 8 ns
Polarity control	Yes
Encoders	• 4 quadrature encoders with A/B and Z inputs • 32-bit position counter • Forward and backward counting • Position trigger support • Noise filtering
Timers	• 4 general purpose timers • Configurable delay and duration • 32-bit accumulator
Event reporting	• 64-bit system timestamp event reporting • Each I/O line can generate event on configurable edge • Each Timer can generate event • Each encoder can generate event
Frame Grabber Synchronization
Synchronization	Precise area and line-scan cameras synchronization across different frame grabbers
Area-Scan Camera Control
Trigger	• Precise control of asynchronous reset cameras, with exposure control • Support of camera exposure/readout overlap • Support of triggering from encoder or timer • Support of external hardware trigger, with optional delay, filtering and trigger decimation
Strobe	Accurate control of the strobe position for strobe light sources. Support of early and late strobe pulses
Line-Scan Camera Control
Scan/page trigger	• Precise control of start-of-scan andend-of-scan triggers • Support of external hardware trigger, with optional delay and filtering • Support of triggering from encoder • Support of infinite acquisition without missing lines
Line trigger	Support for quadrature motion encoders, with programmable filters, selection of acquisition direction and backward motion compensation
Line strobe	Accurate control of the strobe position for strobe light sources
On-Board Processing
On-board memory	4 GB DDR4
Bayer De-Mosaic	• Full 16-bit resolution • Bilinear 3×3 • Bilinear 3×2 for linescan with gradient correction
Color transformation	• Full 16-bit resolution 18-bit coefficients table • Color space conversion • Gain and Offset
Decimation	Line skip
Additional features	Unpacking of 10/12/14-bit to 16-bit LSB aligned
Frame timestamp	64-bit with 8 ns precision
Data stream statistics	Measurement of: • Frame rate • CRC Errors • Received/Dropped frames • Received/Dropped packets • Test packets
Event signaling and counting	The application software can be notified of the occurrence of various events: • Newly acquired buffers • I/O events • Timer events • Encoder events
Software
Host PC operating system	• Microsoft Windows 10 64-bit version • Microsoft Windows 11 64-bit version • Signed and certified kernel driver supporting Windows 10 and 11 • Source code Linux kernel driver (Automaticlly compiled during installation) • Tested for Ubuntu 18.04, 20.04 and 22.04 versions • Nvidia Xavier AGX (Jetpack 5.1.1 and 4.6.1) • Nvidia Orin AGX (Jetpack 5.1.1)
Gen*Cam	• Support of GenCam 3.2 • Full camera and Frame Grabber parameters configuration
Buffer management	• Circular buffer support • Accumulation of several frames/lines to single buffer to reduce CPU load • Flexible buffer queuing • DMA Buffer filling directly to system memory
GUI	• Supported for Windows and Linux OS • Multi camera display and configuration • Image/video recording and playback
Debugging capabilities	• Event logging • Statistics counters
APIs	• Gen*Cam, GenTL producer libraries, ANSI C, Python and NET bindings • x86 64 dynamic library designed to be used with ISO-compliant C runtime • Allows for development of x86 64 applications • Plug-in modules for Matlab, HALCON, Cognex and Labview • Export straightforward, unified and easy-to-use API across all Grabber types • Include practical examples based on API functions, for supported language wrappers • Documentation include sample snippets for API usage
Environmental Conditions
Operating ambient air temperature	0°C to +50°C ( 32°F to +122°F)
Operating ambient air humidity	10% to 90% RH non-condensing
Storage ambient air temperature	-20°C to +70°C ( -4°F to +158°F)
Storage ambient air humidity	10% to 90% RH non-condensing
Certifications
Electromagnetic – EMC standards	• The European Council EMC Directive 2004/108/EC • The Unites States FCC rule 47 CFR 15
EMC – Emission	• EN 55022:2010 Class B • FCC 47 Part 15 Class B
EMC – Immunity	• EN 55024:2010 Class B • EN 61000-4-3 • EN 61000-4-4 • EN 61000-4-6
Flammability	PCB compliant with UL 94 V-0
RoHS	Compliant with the European Union Directive 2011/65/EU (RoHS2)
REACH	Compliant with the European Union Regulation No 1907/2006
WEEE	Must be disposed of separately from normal household waste and must be recycled according to local regulations
Ordering Information
Part Number	KY-FGK-III-CXP
Optional accessories	• CoaXPress cables
